Three-Phase Meter Boards

Heavy commercial direct-connect 3-phase metering boards with sealed utility compartments and tenant MCCB protection

Open sizing tools ↓Enquire about this application ↗

Three-Phase Multi-Tenant Metering Panels

Three-phase metering boards serve premises that need three-phase supplies for plant, HVAC and commercial equipment. The pictured Hager Australian reference provides three prewired three-phase meter positions; it is a metering cabinet rather than a main-switchgear lineup.

The utility and exact meter determine whether direct connection or CT-operated metering is appropriate. Agree the tenant currents, metering layout, neutral arrangement, protective devices and sealing details before manufacture. The reference photograph does not establish KPLC approval.

Equipment & Range Highlights

Three-phase meteringPictured: Hager VYGMV3W-3P three-way three-phase group-metering enclosure.

Three-Phase Group-Metering Boards

Hager VYGMV3W-3P shows an Australian prewired cabinet for three three-phase meter positions. It is a metering-board reference, not an ABB main-switchboard lineup. Revenue meters and final Kenyan utility configuration are selected separately.

Pictured positions3 three-phase meters

ReferenceHager VYGMV3W-3P

MetersNot supplied

Feeder protectionPictured: LOVATO Electric Moulded case circuit breakers family.

Moulded-Case Circuit Breakers (MCCB)

LOVATO MCCB family reference for incoming and outgoing feeders. Frame size, trip-unit settings, pole count and Icu/Ics breaking capacities are selected from the exact model datasheet at the installation voltage.

Trip unitModel-dependent

Icu / IcsAt rated voltage

CoordinationManufacturer tables

Explore Moulded-Case Circuit Breakers (MCCB)

Three-Phase Meter Panel Specifications

Selection item	Engineering requirement
Pictured reference	Hager VYGMV3W-3P: three three-phase meter positions in an Australian prewired cabinet; meters not supplied.
Direct or CT connection	The utility and exact meter determine the permitted direct-connected current; obtain the approved metering arrangement.
Kenyan configuration	Confirm utility drawings, meter footprint, sealing, incomer, neutral and earthing arrangements before manufacture. Australian references are not KPLC approvals.
Assembly standard	Specify the applicable IEC 61439 part and verification for the actual supplied assembly. AS/NZS references show an IEC-aligned enclosure approach.
Meter supply	Revenue meters, private meters and communication modules are separately defined in the approved schedule.
Protection	Select current, fault performance, residual-current protection and isolation from the design; not from the photograph.

Engineering & Build Highlights

Form 2b internal separation between main incoming busbars, meter chamber, and tenant outgoing breakers
Ample cable spreaders accommodate heavy 4-core armoured cables for each tenant shop or unit
Specify conductor identification, terminal numbering and phase colours in the approved wiring schedule
UV-resistant polycarbonate viewing windows over every three-phase meter position
External padlocking handle with 3-point latching mechanism for heavy commercial security
Anti-condensation ventilation louvres with internal fine dust mesh filters
