LED Panel Troffers & Commercial Lighting

Q: What is the difference between Backlit and Edge-lit LED panels?

Edge-lit panels are ultra-thin (9mm) with LEDs mounted on the sides firing through a light guide plate. Backlit panels (approx. 30mm depth) mount LEDs directly behind the diffuser, providing higher energy efficacy (up to 140 lm/W) and eliminating the risk of light guide yellowing over time.

Q: Can these panels be dimmed using a central Building Management System (BMS)?

Yes. We supply panels fitted with DALI-2 or 0-10V dimmable drivers that connect directly to your lighting control system for automated daylight harvesting and scheduling.

Low-glare (UGR < 19) backlit and edge-lit LED ceiling panels for offices, hospitals and educational facilities

LED Panel Troffers & Commercial Lighting — engineering concept

Open sizing tools ↓Enquire about this application ↗

Commercial LED Panel Troffers

Commercial corporate offices, hospitals, banks, and schools require glare-free, uniform ceiling illumination that enhances concentration and visual comfort. Nairobi Power Engineers supplies high-performance 600x600mm and 1200x600mm LED Panel Troffers engineered to British Standard BS EN 12464-1.

Featuring micro-prismatic diffusers achieving Unified Glare Rating UGR < 19, flicker-free external drivers, high colour rendering (CRI ≥ 85), and seamless extruded aluminium frames, our LED panels directly replace outdated fluorescent tube fittings in standard T-bar grid and plasterboard ceilings.

Equipment & Range Highlights

Commercial Standard • 600x600 mm

Conceptual led panel troffers & commercial lighting scene; exact specifications vary.

600x600 mm Low-Glare LED Ceiling Panels

Ultra-slim 36W / 40W LED panels with micro-prismatic optics (UGR < 19), 4800 lumens output, and flicker-free constant-current drivers.

Size595 × 595 mm (T-Bar Grid)

Power36 W / 40 W (120–140 lm/W)

GlareUGR < 19 Office Certified

Large Format • 1200x600 mm

Conceptual led panel troffers & commercial lighting scene; exact specifications vary.

1200x600 mm High-Output Commercial Troffers

Large-format commercial panels delivering 7200 lumens for executive boardrooms, open-plan call centres, and hospital corridors.

Size1195 × 595 mm

Power60 W / 72 W

CCT4000 K Neutral / 6000 K Daylight

LED Panel Technical Reference

Parameter	Specification Details
Dimensions Available	595×595 mm (600x600), 1195×295 mm (1200x300), 1195×595 mm (1200x600)
Power Consumption	36 W, 40 W, 48 W, 60 W, 72 W
Luminous Efficacy	120 – 140 lumens per watt (Up to 5,600 lm for 40W)
Unified Glare Rating (UGR)	UGR < 19 micro-prismatic diffuser (EN 12464 compliant for screen work)
Colour Rendering Index	Ra ≥ 85 (High colour fidelity)
Driver Options	Standard On/Off, DALI-2 dimmable, 0-10V dimmable, 3-Hour Emergency Battery Pack

Engineering & Build Highlights

Micro-prismatic optical diffuser eliminates direct harsh glare and specular reflection on computer screens
Flicker-free ripple-free external driver prevents eye strain, headaches, and camera screen banding
High-grade PMMA light guide plate will not yellow or discolor over 10+ years of operation
Rigid seamless anodized aluminium frame prevents light leakage and structural warping
Versatile mounting options: recessed in T-bar ceiling grid, surface-mount frame, or suspended with wire kits
Optional 3-hour emergency backup battery pack powers the panel at 20% brightness during power outages

Target Applications & Sectors

Commercial corporate office suites & boardroomsHospital patient wards, consultation rooms & corridorsUniversity lecture halls & school classroomsBanking branch halls & call centre floorsRetail commercial shops & boutique showroomsPharmaceutical laboratories & cleanroom facilities

Edge-lit panels are ultra-thin (9mm) with LEDs mounted on the sides firing through a light guide plate. Backlit panels (approx. 30mm depth) mount LEDs directly behind the diffuser, providing higher energy efficacy (up to 140 lm/W) and eliminating the risk of light guide yellowing over time.

Yes. We supply panels fitted with DALI-2 or 0-10V dimmable drivers that connect directly to your lighting control system for automated daylight harvesting and scheduling.

Order Commercial LED Panels

Contact our lighting team for bulk commercial contractor pricing and sample units.

Discuss Your Requirement

Explore your requirements.

Try the tools relevant to led panel troffers & commercial lighting, compare scenarios, then send the inputs to our team.

Enable JavaScript for live calculations, or ask our engineering team.

Conceptual engineering scenes illustrate applications. Manufacturer reference photos are identified separately. Confirm exact models, dimensions and ratings before ordering.
