LED Floodlighting & Street Lighting Luminaires

Overview

Outdoor Floodlighting & Street Lighting

Highways, commercial compounds, sports facilities, and seaport container terminals demand rugged, high-output outdoor luminaires that withstand heavy rain, lightning surges, and continuous high-temperature exposure. Nairobi Power Engineers supplies professional LED Floodlights and Street Lighting systems.

Engineered with die-cast marine-grade aluminium housings (IP66, IK10), high-efficiency Lumileds/Cree LED arrays (up to 160 lm/W), asymmetric optical distributions (Type II, III, IV), built-in 10kV/20kV surge protection devices, and 7-pin NEMA/Zhaga photocell sockets, our luminaires deliver powerful illumination with zero maintenance.

Product Lineup

Equipment & Range Highlights

Heavy Area • 50W to 1000W

High-Power Architectural & Sports Floodlights

Heavy-duty IP66 floodlights with precision asymmetrical beam reflectors for compound security, high-mast illumination, and sports arenas.

Power50W, 100W, 200W, 400W, 600W, 1000W

Luminous OutputUp to 150,000 Lumens

Ingress & ImpactIP66 • IK10 Vandal-Proof

Roadway Optics • 30W to 240W

Aerodynamic LED Street Lighting Luminaires

Die-cast roadway luminaires with Type II/III optical batwing distribution, tool-less maintenance latch, and photocell socket.

Power30W, 60W, 90W, 120W, 150W, 240W

Photocell7-Pin NEMA / Zhaga Socket

SpigotUniversal 60mm / 76mm Entry

Outdoor Specs

Outdoor Lighting Engineering Reference

Luminaire Type	Available Wattages	Luminous Efficacy	Optical Beam Types	Surge Protection
Security & Compound Floodlights	50 W, 100 W, 150 W, 200 W	140 – 155 lm/W	60° / 90° / 120° Symmetrical	10 kV Integrated SPD
High-Mast & Stadium Floodlights	400 W, 600 W, 1000 W	150 – 160 lm/W	15° / 30° / 60° Narrow & Asymmetric	20 kV Heavy Duty SPD
Urban Roadway Streetlights	30 W, 60 W, 90 W, 120 W	145 – 160 lm/W	Type II / Type III Batwing Roadway	10 kV Integrated SPD
Highway & Expressway Streetlights	150 W, 180 W, 240 W	150 – 160 lm/W	Type III / Type IV Wide Roadway	20 kV Heavy Duty SPD

Key Features

Engineering & Build Highlights

Die-cast marine-grade aluminium housing with electrostatically applied anti-corrosion polyester powder coating
Aerodynamic low-windage profile minimizes pole wind-load forces during tropical storms
Asymmetric batwing optical lenses direct light onto roadway and working surfaces without light pollution or sky glow
Integrated 10kV / 20kV surge protection device protects sensitive LED drivers against lightning strikes
Tool-less opening clip with automatic power disconnect knife switch ensures safe maintenance on elevated bucket trucks
Compatible with NEMA 7-pin photocell receptacles and smart LoRaWAN/Zigbee central management systems (CMS)

Applications

Target Applications & Sectors

Highways, urban expressways & municipal streetsCommercial perimeter security & compound illuminationSeaport container terminals & freight logistics yardsSports stadiums, football arenas & tennis courtsAirport aprons, taxiways & parking facilitiesMining haul roads, quarries & industrial stockyards

FAQs

Asymmetrical (batwing) lenses stretch light lengthwise along the road surface and forward across lanes, ensuring uniform illumination without dark spots between poles while eliminating glare in drivers’ eyes.

Outdoor poles act as lightning rods during thunderstorms. Our 10kV/20kV surge protection devices (SPDs) clamp high-voltage transients to earth before they reach the delicate semiconductor driver and LED diodes.
